co-ax同軸閥VFK 32
二位三通外部控制式同軸閥
VMK / VFK 32 DR
特性
端口 螺紋 G 1 1/4 - G 1 1/2
法蘭 PN 16/40/100
功能 NC
壓力范圍 0-16 / 0-40 / 0-64 / 0-100 bar
A B max. 100 bar
B A max. 16 bar
A C max. 100 bar
C A max. 100 bar
KV值 18,9 m3/h
介質 氣態? 液態? 高粘稠? 凝膠狀? 漿狀? 高污染?
流向 見壓力范圍
開關周期 150 1/min
開關時間 打開 100-3000 ms
關閉 100-3000 ms
介質溫度 60 °C 直接安裝的先導閥
環境溫度 50 °C 直接安裝的先導閥
重量 VMK 8,5 kg
VFK 10,2 kg
標稱電壓 Un 24 V DC
Un 230 V 40-60 Hz AC
防護等級 IP65 (P54) DIN 40 050
負載率 ED 100%、
閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.
