stober聯軸器PA系列

金石宇 QQ：2850590587   手機：17316071353 電話：010-64714988-212 傳真：010-64714988668 郵件：tk6@handelsen.cn

PA系列

滿足最高要求的精度。斜齒輪。高扭轉剛度。背隙小于1 arcmin。堅固的實心軸。短電動機適配器，帶有集成的駐車制動器和插入式聯軸器。簡易安全的電機安裝。可以連接到幾乎任何品牌的伺服電機上。



軸設計

-實心軸帶鍵

-實心軸帶鍵



軸承設計

-加強型軸承，具有更高的軸向負載能力（選件）



安裝位置

-任何安裝位置。



潤滑劑和保養

-合成潤滑劑CLP HC ISO VG 150-

終身潤滑

-免維護



油漆面漆

黑色RAL 9005



電機適配器MB

-集成的靜態電流制動器。

-作為單制動器，或者-與電動機制動器一起-作為冗余制動系統。

-適用于所有普通同步伺服電機的電機適配器。

-插入式聯軸器，便于在任何位置拆下帶有制動軸的電動機。



外殼類型

IP54，可選IP65



電氣連接

-帶接線盒和集成發布監控的標準設計。

-可選帶連接器，但不與電氣監控結合使用。



卷材

-線圈連接24 VDC-

線圈連接104 VDC（連接電壓220 – 277 V，±5％，50 // 60 Hz），帶高速整流器。

有關詳細信息，請參見 操作說明制動模塊MB ID 441846



選件手動釋放

用手松開可以使制動器機械釋放。





推薦電機

EZ同步伺服電動機

stobe減速機P系列

軸設計

 - 帶鑰匙的實心軸

 - 沒有鑰匙的實心軸



軸承設計

 - 普通軸承

 - 增強軸承，提高軸向負載能力（可選）

 - 增強軸承，提供更高的徑向負載能力（可選）



安裝位置

 - 任何安裝位置。



潤滑劑和維護

 - 合成潤滑劑CLP HC ISO VG 150

 - 終身潤滑

 - 免維護



油漆完成

 - 外殼和連接器黑色RAL 9005

 - 電機蓋b側洋紅色RAL 4010



同步伺服電機EZ

 - 非常緊湊。

 - 每單位體積的最高功率。

 - 扭矩大。

 - 高動態。



同步伺服電機EZ

外部風扇

 - 根據DIN EN 60034-6，IC416

 - 增加扭矩和連續性能。

 - 如果周圍溫度較高。

 - 也可作為改裝套件提供。



外部風扇

電機制動器

可選地，電動機b側可以配備永磁體保持制動器。



EZ制動器

編碼器

絕對值編碼器EnDat?2.1或EnDat?2.2

 - 光學或電感測量原理

 - 高系統精度，分辨率高達23位

 - 多圈版本中最多可達4096個可錄制分辨率

 - 電子銘牌確?？焖俸啽愕恼{(diào)試

 - 使用位置值傳輸?shù)母郊有畔ⅲ‥nDat?2.2）

 - 兼容許多第三方制造商的STOBER驅動控制器和驅動控制器



分解器

 - 耐高溫

 - 高振動強度和抗沖擊性



電源和編碼器接口

 - 帶快速鎖定的旋轉插頭連接器。

 - 選項：提供配套連接器。



EZ連接方法

編碼器單電纜解決方案（OCS）

HIPERFACE DSL單電纜解決方案（OCS）

 - 通過取消編碼器電纜顯著減少布線工作量

 - 通過取消編碼器插頭連接器，顯著減少了空間需求

 - 高系統精度，分辨率高達20位

 - 多圈版本中最多可達4096個可錄制分辨率

 - 電子銘牌確?？焖俸啽愕恼{(diào)試

 - 使用位置值傳輸?shù)母郊有畔?/p>



電源和編碼器接口一個電纜解決方案（OCS）

 - 帶快速鎖定的旋轉插頭連接器（編碼器和驅動控制器之間的連接線路沿著電機的電源線布線）。

 - 選項：提供配套連接器。



EZ連接方法（OCS）

繞組保護

PTC熱敏電阻安裝在STOBER同步伺服電機中作為配置功能，以實現熱繞組保護。這使得電動機可以在關閉適當?shù)难b置時超過允許的最大繞組溫度。



驅動控制器建議

 -  POSIDRIVE MDS 5000，功率范圍0.75至45 kW

 -  POSIDYN SDS 5000，功率范圍0.75至45 kW

 -  SD6功率范圍0.75 kW至45 kW

 -  SI6功率范圍0.75 kW至25.9 kW
