ATB低壓電機的技術參數介紹
類： 安全區域
范圍： 0.06 千瓦 - 2，000 千瓦
大?。?span style="-webkit-tap-highlight-color: transparent; box-sizing: border-box; white-space: pre;"> 56 - 710
極數： 2、4、6、8 及以上
保護： IP 23、IP 55 及以上
ATB電機漢達森品牌專員吳亞男
熱類： 155 （F）， 180 （H）
冷卻： TEFC， ODP
ATB CD80K-4, 288 467, 1995-06-21
ATB CD90L1-4, 228 466, 1995-06-22
ATB CD100L1-4, 228 465, 1995-06-21
ATB CD112M-2, 228 412, 1995-06-21
ATB CD132S1-2, 228 726, 1996-12-18
ATB CD160M1-2, 229 727, 1997-06-11
ATB dCD 225 M-2,
ATB電機漢達森品牌專員吳亞男
ATB CD250M-2, 230 235, 1998-03-09
ATB CD280S-2, 230 461, 1998-07-09
ATB CD315S-2, 229 524, 1997-04-22
ATB CD315L2-2; 230269; 1998-04-30
ATB Motor no. 234 760 2 Pole Motors
ATB CD71K-2/0.37KW 16kg 30mm 14mm 1xM25
ATB CD71L-2/0.55KW 17kg 30mm 14mm 1xM25
ATB CD80K-2/0.75KW 24kg 40mm 19mm 1xM25
ATB CD80L-2/1.1KW 25kg 40mm 19mm 1xM25
ATB CD90L1-2/1.5KW 31kg 50mm 24mm 1xM25
ATB CD90L2-2/2.2KW 35kg 50mm 24mm 1xM25
ATB CD100L-2/3.0KW 45kg 60mm 28mm 1xM32
ATB CD112M-2/4.0KW 53kg 60mm 28mm 1xM32
ATB CD132S1-2/5.5KW 95kg 80mm 38mm 1xM32
ATB CD132S2-2/7.5KW 100kg 80mm 38mm 1xM324 Pole Motors
ATB CD71K-4/0.25KW 16kg 30mm 14mm 1xM25
ATB CD71L-4/0.37KW 17kg 30mm 14mm 1xM25
ATB CD80K-4/0.55KW 24kg 40mm 19mm 1xM25
ATB CD80L-4/0.75KW 25kg 40mm 19mm 1xM25
ATB CD90L1-4/1.1KW 31kg 50mm 24mm 1xM25
ATB CD90L2-4/1.5KW 35kg 50mm 24mm 1xM25
ATB CD100L1-4/2.2KW 44kg 60mm 28mm 1xM32
ATB CD100L2-4/3.0KW 46kg 60mm 28mm 1xM32
ATB電機漢達森品牌專員吳亞男
ATB CD112M-4/4.0KW 59kg 60mm 28mm 1xM32
ATB CD132S-4/5.5KW 100kg 80mm 38mm 1xM32
ATB CD132M-4/7.5KW 110kg 80mm 38mm 1xM40
ATB CD160M-4/11.0KW 168kg 110mm 42mm 1xM40
ATB CD80K-4, 288 467, 1995-06-21
ATB CD90L1-4, 228 466, 1995-06-22
ATB CD100L1-4, 228 465, 1995-06-21
ATB CD112M-2, 228 412, 1995-06-21
ATB CD132S1-2, 228 726, 1996-12-18
ATB CD160M1-2, 229 727, 1997-06-11
ATB CD 225 M-2,
ATB CD250M-2, 230 235, 1998-03-09
ATB CD280S-2, 230 461, 1998-07-09
ATB CD315S-2, 229 524, 1997-04-22
ATB CD315L2-2; 230269; 1998-04-30
ATB Motor no. 234 760 2 Pole Motors
ATB CD71K-2/0.37KW 16kg 30mm 14mm 1xM25
ATB CD71L-2/0.55KW 17kg 30mm 14mm 1xM25
ATB CD80K-2/0.75KW 24kg 40mm 19mm 1xM25
ATB CD80L-2/1.1KW 25kg 40mm 19mm 1xM25
ATB CD90L1-2/1.5KW 31kg 50mm 24mm 1xM25
ATB CD90L2-2/2.2KW 35kg 50mm 24mm 1xM25
ATB CD100L-2/3.0KW 45kg 60mm 28mm 1xM32
ATB CD112M-2/4.0KW 53kg 60mm 28mm 1xM32
ATB CD132S1-2/5.5KW 95kg 80mm 38mm 1xM32
ATB CD132S2-2/7.5KW 100kg 80mm 38mm 1xM324 Pole Motors
ATB CD71K-4/0.25KW 16kg 30mm 14mm 1xM25
ATB CD71L-4/0.37KW 17kg 30mm 14mm 1xM25
ATB CD80K-4/0.55KW 24kg 40mm 19mm 1xM25
ATB電機漢達森品牌專員吳亞男
ATB CD80L-4/0.75KW 25kg 40mm 19mm 1xM25
ATB CD90L1-4/1.1KW 31kg 50mm 24mm 1xM25
ATB CD90L2-4/1.5KW 35kg 50mm 24mm 1xM25
ATB CD100L1-4/2.2KW 44kg 60mm 28mm 1xM32
ATB CD100L2-4/3.0KW 46kg 60mm 28mm 1xM32
ATB CD112M-4/4.0KW 59kg 60mm 28mm 1xM32
ATB CD132S-4/5.5KW 100kg 80mm 38mm 1xM3
ATB 2CD132M-4/7.5KW 110kg 80mm 38mm 1xM40
ATB
CD160M-4/11.0KW 168kg 110mm 42mm 1xM40
北京漢達森德國本土采購，拼箱發貨報關，德國技術，終身售后服務，貨期保證，價格公道，歡迎垂詢!如需更多信息歡迎垂詢漢達森品牌專員吳亞男
