co-ax直動式同軸閥MK 10 DR
特性
端口 螺紋 G 1/4 - G 3/4
功能 NC
壓力范圍 0-40 / 0-100 bar
KV值 0 - 40 bar: 2,2 m³/h
0 - 100 bar:1,4 m³/h
介質 氣態 液態 高污染
co-ax直動式同軸閥MK 10 DR
流向 見壓力范圍
開關周期 200 1/min
開關時間 打開 135 ms
關閉 20 ms
介質溫度 DC -10 °C — +80 °C
AC -10 °C — +80 °C
環境溫度 DC -10 °C — +80 °C
AC -10 °C — +80 °C
重量 2,5 kg
標稱電壓 Un 24 V DC
Un 230 V 40-60 Hz AC
驅動 DC 直流電磁鐵
AC 內置式整流器的直流電磁鐵
絕緣等級 H 180 °C
防護等級 IP65
負載率 ED 100%
連接 按DIN EN175301-803標準的插頭, 形式A 4個位置X90°, 電線直徑 6-8 mm
M12x1 按DESINA標準的接頭 / VDMA
閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.
