BEHLKE高壓開關HTS 31-03-HB-C
德國BEHLKE是高壓功率半導體堆棧的全球市場領導者。BEHLKE生產的高壓固態開關zui高可達200kV交流和直流單開關或橋式配置。 BEHLKE擁有600多種標準開關和脈沖發生器的產品系列基于高度靈活的設計。 因此，BEHLKE可以進行大量的技術改進，以及完整的定制解決方案。
主要產品：
BEHLKE高壓開關、BEHLKE高壓脈沖單元、BEHLKE快速恢復高壓二極管組件
高壓開關，可變導通時間，推挽式，MOSFET
●采用半橋配置的HV推挽式開關
●兩個切換路徑，可實現快速上升和下降時間
●由于被動切換路徑鎖定而安全運行
●無交叉電流
●非常適合將精確的HV方波脈沖轉換為容性負載
●無需工作電阻
●無需大型高壓輸入儲能電容器
注意：快速推挽式開關（半橋）對感應負載的反向電流或增加的接線電感非常敏感。反向電流可能以不確定的方式導通本征（寄生）MOSFET二極管。這可能導致橋切換路徑內的短路，進一步導致災難性故障。請務必確保沒有電流回到開關的輸出端。這應該通過最大的示波器測量來驗證。實際工作電壓的10％。請將足夠的緩沖電容（最好是陶瓷類型）直接連接到HV輸入，并在輸出長的情況下使用足夠的串聯阻尼電阻。 MOSFET開關的電感負載需要一個快速的續流二極管網絡（串聯阻塞二極管+并聯續流二極管）。該保護二極管網絡可以通過BEHLKE FDA系列的單個二極管安裝在外部。它也可以作為選件I-FWDN集成到開關模塊中。請仔細閱讀一般說明。
技術說明：BEHLKE推挽式開關具有極大的上升和下降時間。如果您的應用不需要完整的開關速度，我們建議您使用速度限制選項S-TT（上升和下降時間減慢約50％）與輸入低通濾波器選項LP結合使用。這些選項有助于最小化快速高壓脈沖電路典型的高頻困難（例如自振蕩或自重啟動）并簡化EMC設計。
產品代碼：型號包含有關電壓，電流和開啟行為的編碼信息。第一個數字代表以kV為單位的電壓，短劃線前的最后一個數字表示開啟行為（0 =固定導通時間，1 =可變導通時間）。短劃線后面的數字表示以安培x10為單位的電流。特殊功能在第二個破折號后由字母編碼。示例HTS 31-03-HB-C：HTS = HV晶體管開關，3 = 3kV，1 =可變導通時間，03 = 30安培，HB =半橋，C =緊湊型系列。
緊湊型系列。 自感低，轉換時間短。 良好的瞬態免疫力 請向下滾動以查看該選項標準系列。 優選地，對于低容性負載下的較高開關頻率。
型號：
Behlke HTS 11-07-HB-C
Behlke HTS 21-07-HB-C
Behlke HTS 31-03-HB-C
Behlke HTS 31-13-HB-B-C
Behlke HTS 41-02-HB-LC-C
Behlke HTS 61-01-HB-C
Behlke HTS 61-03-HB-C
Behlke HTS 71-13-HB-B-C
Behlke HTS 91-01-HB-C
Behlke HTS 91-02-HB-LC-C
Behlke HTS 111-13-HB-B-C
Behlke HTS 121-01-HB-C
Behlke HTS 181-01-HB-C
Behlke HTS 31-480-SI
Behlke HTS 51-240-SI
Behlke HTS 61-240-SI
Behlke HTS 31-320-FI
Behlke HTS 51-160-FI
Behlke HTS 61-160-FI
Behlke HTS 101-120-SI
Behlke HTS 101-80-FI
Behlke HTS 31-960-SI
Behlke HTS 61-480-SI
Behlke HTS 31-640-FI
Behlke HTS 61-320-FI
Behlke HTS 121-240-SI
Behlke HTS 121-160-FI
Behlke HTS 91-480-SI
Behlke HTS 181-240-SI
Behlke HTS 91-320-FI
Behlke HTS 181-160-FI
Behlke HTS 181-400-FI
Behlke HTS 361-200-FI
Behlke HTS 61-15-SiC
Behlke HTS 61-30-SiC
Behlke HTS 61-60-SiC
Behlke HTS 61-120-SiC
Behlke HTS 121-15-SiC
Behlke HTS 121-30-SiC
Behlke HTS 121-60-SiC
Behlke HTS 121-120-SiC
Behlke HTS 121-180-SiC
Behlke HTS 121-360-SiC
Behlke HTS 151-15-SiC
Behlke HTS 151-30-SiC
Behlke HTS 151-60-SiC
Behlke HTS 151-120-SiC
Behlke HTS 151-180-SiC
Behlke HTS 151-360-SiC
Behlke HTS 201-15-SiC
Behlke HTS 201-30-SiC
Behlke HTS 201-60-SiC
Behlke HTS 201-120-SiC
Behlke HTS 201-180-SiC
Behlke HTS 201-240-SiC
Behlke HTS 201-300-SiC
Behlke HTS 201-600-SiC
Behlke HTS 241-15-SiC
Behlke HTS 241-30-SiC
Behlke HTS 241-60-SiC
Behlke HTS 241-120-SiC
Behlke HTS 241-180-SiC
Behlke HTS 241-240-SiC
Behlke HTS 241-300-SiC
Behlke HTS 241-600-SiC
Behlke HTS 301-15-SiC
Behlke HTS 301-30-SiC
Behlke HTS 301-60-SiC
Behlke HTS 301-120-SiC
Behlke HTS 301-180-SiC
Behlke HTS 301-240-SiC
Behlke HTS 301-300-SiC
Behlke HTS 301-600-SiC
Behlke HTS 401-15-SiC
Behlke HTS 401-30-SiC
Behlke HTS 401-60-SiC
Behlke HTS 401-120-SiC
Behlke HTS 401-180-SiC
Behlke HTS 401-240-SiC
Behlke HTS 401-300-SiC
Behlke HTS 401-600-SiC
Behlke HTS 501-15-SiC
Behlke HTS 501-30-SiC
Behlke HTS 501-60-SiC
Behlke HTS 501-120-SiC
Behlke HTS 501-240-SiC
Behlke HTS 501-480-SiC
Behlke HTS 701-15-SiC
Behlke HTS 701-30-SiC
Behlke HTS 701-60-SiC
Behlke HTS 701-120-SiC
Behlke HTS 701-180-SiC
Behlke HTS 701-240-SiC
Behlke HTS 901-15-SiC
Behlke HTS 901-30-SiC
Behlke HTS 901-60-SiC
Behlke HTS 901-120-SiC
Behlke HTS 901-180-SiC
Behlke HTS 1001-15-SiC
Behlke HTS 1001-30-SiC
Behlke HTS 1001-60-SiC
Behlke HTS 1001-120-SiC
Behlke HTS 1001-180-SiC
Behlke HTS 1201-15-SiC
Behlke HTS 1201-30-SiC
Behlke HTS 1201-60-SiC
Behlke HTS 1201-120-SiC
Behlke HTS 1401-15-SiC
Behlke HTS 1401-30-SiC
Behlke HTS 1401-60-SiC
Behlke HTS 1401-120-SiC
Behlke HTS 1601-15-SiC
Behlke HTS 1601-30-SiC
Behlke HTS 1601-60-SiC
Behlke HTS 1601-120-SiC
Behlke HTS 61-10-LC2
Behlke HTS 61-20-LC2
Behlke HTS 61-40-LC2
Behlke HTS 61-80-LC2
Behlke HTS 121-10-LC2
Behlke HTS 121-20-LC2
Behlke HTS 121-40-LC2
Behlke HTS 121-80-LC2
Behlke HTS 121-120-LC2
Behlke HTS 121-240-LC2
Behlke HTS 151-10-LC2
Behlke HTS 151-20-LC2
Behlke HTS 151-40-LC2
Behlke HTS 151-80-LC2
Behlke HTS 151-120-LC2
Behlke HTS 151-240-LC2
Behlke HTS 201-10-LC2
Behlke HTS 201-20-LC2
Behlke HTS 201-40-LC2
Behlke HTS 201-80-LC2
Behlke HTS 201-120-LC2
Behlke HTS 201-160-LC2
Behlke HTS 201-200-LC2
Behlke HTS 201-400-LC2
Behlke HTS 241-10-LC2
Behlke HTS 241-20-LC2
Behlke HTS 241-40-LC2
Behlke HTS 241-80-LC2
Behlke HTS 241-120-LC2
Behlke HTS 241-160-LC2
Behlke HTS 241-200-LC2
Behlke HTS 241-400-LC2
Behlke HTS 301-10-LC2
Behlke HTS 301-20-LC2
Behlke HTS 301-40-LC2
Behlke HTS 301-80-LC2
Behlke HTS 301-120-LC2
Behlke HTS 301-160-LC2
Behlke HTS 301-200-LC2
Behlke HTS 301-400-LC2
Behlke HTS 401-10-LC2
Behlke HTS 401-20-LC2
Behlke HTS 401-40-LC2
Behlke HTS 401-80-LC2
Behlke HTS 401-120-LC2
Behlke HTS 401-160-LC2
Behlke HTS 401-200-LC2
Behlke HTS 401-400-LC2
Behlke HTS 501-10-LC2
Behlke HTS 501-20-LC2
Behlke HTS 501-40-LC2
Behlke HTS 501-80-LC2
Behlke HTS 501-160-LC2
Behlke HTS 501-320-LC2
Behlke HTS 701-10-LC2
Behlke HTS 701-20-LC2
Behlke HTS 701-40-LC2
Behlke HTS 701-80-LC2
Behlke HTS 701-120-LC2
Behlke HTS 701-160-LC2
Behlke HTS 901-10-LC2
Behlke HTS 901-20-LC2
Behlke HTS 901-40-LC2
Behlke HTS 901-80-LC2
Behlke HTS 901-120-LC2
Behlke HTS 1001-10-LC2
Behlke HTS 1001-20-LC2
Behlke HTS 1001-40-LC2
Behlke HTS 1001-80-LC2
Behlke HTS 1001-120-LC2
Behlke HTS 1201-10-LC2
Behlke HTS 1201-20-LC2
Behlke HTS 1201-40-LC2
Behlke HTS 1201-80-LC2
Behlke HTS 1401-10-LC2
Behlke HTS 1401-20-LC2
Behlke HTS 1401-40-LC2
Behlke HTS 1401-80-LC2
Behlke HTS 11-14-C
Behlke HTS 21-07-C
Behlke HTS 31-06-C
Behlke HTS 31-05-C
Behlke HTS 41-05-C
Behlke HTS 61-03-C
Behlke HTS 71-02-LC-C
Behlke HTS 91-02-C
Behlke HTS 121-01-C
Behlke HTS 181-01-C
Behlke HTS 61-06-C
Behlke HTS 101-02-LC-C
Behlke HTS 91-05-C
Behlke HTS 121-03-C
Behlke HTS 181-02-C
Behlke HTS 241-01-C
Behlke HTS 361-01-C
Behlke HTS 051-64
Behlke HTS 11-30
Behlke HTS 21-14
Behlke HTS 31-06
Behlke HTS 41-03
Behlke HTS 51-06
Behlke HTS 61-03
Behlke HTS 61-02
Behlke HTS 61-05.
Behlke HTS 101-01
Behlke HTS 101-03
Behlke HTS 151-01
Behlke HTS 151-02
Behlke HTS 71-06
Behlke HTS 71-12
Behlke HTS 141-03
Behlke HTS 141-06
Behlke HTS 21-50
Behlke HTS 51-20
Behlke HTS 81-09
Behlke HTS 91-06
Behlke HTS 91-12
Behlke HTS 161-03
Behlke HTS 161-06
Behlke HTS 181-06
Behlke HTS 111-12
Behlke HTS 221-03
Behlke HTS 221-06
Behlke HTS 241-06
Behlke HTS 181-12
Behlke HTS 331-03
Behlke HTS 331-06
Behlke HTS 361-06
Behlke HTS 40-06-B
Behlke HTS 40-12-B
Behlke HTS 90-06-B
Behlke HTS 40-26-B
Behlke HTS 90-13-B
Behlke HTS 100-12-B
Behlke HTS 30-60-B
Behlke HTS 60-24-B
Behlke HTS 60-30-B
Behlke HTS 70-30-B
Behlke HTS 40-60-B
Behlke HTS 90-30-B
Behlke HTS 60-60-B
Behlke HTS 120-30-B
Behlke HTS 160-48-B
Behlke HTS 90-96-B
Behlke HTS 180-48-B
Behlke HTS 120-96-B
Behlke HTS 240-48-B
Behlke HTS 240-104-B
Behlke HTS 30-06-UF
Behlke HTS 30-08-UF
Behlke HTS 50-08-UF
Behlke HTS 50-12-UF
Behlke HTS 80-12-UF
Behlke HTS 80-20-UF
Behlke HTS 100-20-UF
Behlke HTS 120-15-UF
Behlke HTS 40-06
Behlke HTS 50-05
Behlke HTS 60-04
Behlke HTS 80-03
Behlke HTS 160-01
Behlke HTS 20-08
Behlke HTS 30-06
Behlke HTS 50-06
Behlke HTS 90-06
Behlke HTS 150
Behlke HTS 180
Behlke HTS 300
Behlke HTS 340
Behlke HTS 100-20
Behlke HTS 200-10
Behlke HTS 220-10
Behlke HTS 200-20
Behlke HTS 400-10
Behlke HTS 300-20
Behlke HTS 600-10
Behlke HTS 400-20
Behlke HTS 800-10
Behlke HTS 500-10
Behlke HTS 500-20
Behlke HTS 500-80
Behlke HTS 500-160
Behlke HTS 1000-10
Behlke HTS 1000-20
Behlke HTS 1500-10
Behlke HTS 1500-20
Behlke HTS 1500-160
Behlke HTS 2000-160
Behlke HTS 31-80
Behlke HTS 61-40
Behlke HTS 101-20
Behlke HTS 31-160
Behlke HTS 61-80
Behlke HTS 121-40
Behlke HTS 31-240
Behlke HTS 61-120
Behlke HTS 91-80
Behlke HTS 181-40
Behlke HTS 31-320
Behlke HTS 61-160
Behlke HTS 121-80
Behlke HTS 241-40
Behlke HTS 181-200
Behlke HTS 361-100
Behlke HTS 05-160-F
Behlke HTS 10-70-F
Behlke HTS 20-36-F
Behlke HTS 30-12-F
Behlke HTS 50-12-F
Behlke HTS 20-32-F
Behlke HTS 50-16-F
Behlke HTS 60-16-F
Behlke HTS 80-07-F
Behlke HTS 40-32-F
Behlke HTS 80-16-F
Behlke HTS 50-32-F
Behlke HTS 100-16-F
Behlke HTS 140-25-F
Behlke HTS 70-50-F
Behlke HTS 150-25-F
Behlke HTS 100-50-F
Behlke HTS 200-25-F
Behlke HTS 400-12-F
Behlke HTS 901-10-GSM
Behlke HTS 901-20-GSM
Behlke HTS 2000-160
Behlke GHTS-60B
Behlke GHTS 30
Behlke GHTS 100 A
Behlke FSWP 11-07
Behlke FSWP 91-01
BEHLKE高壓開關HTS 31-03-HB-C
