MBS ASK 51.4 2u插入式電流互感器



最小起訂貨量

  • 無限制

您可能還關注相似產品
  • 身份驗證|
  • 主營產品|傳感器
  • 公司榮譽| 已通過認證
供應產品分類
  • 暫無分類
本頁信息為德國mbs原廠生產的產品“MBS ASK 51.4 2u插入式電流互感器”產品信息,如您想了解更多關于“MBS ASK 51.4 2u插入式電流互感器”價格、型號、廠家的相關信息,請致電我們,或QQ在線交談。
品牌MBS 有效期至長期有效 最后更新2020-06-18 17:10
瀏覽次數5

MBS ASK 51.4 2u插入式電流互感器


劉洋
QQ:2850590582  點擊這里給我發消息
手機:17744536447
電話:010-64714988-213
傳真:010-64714988668
郵件:-@handelsen.cn
劉洋郵箱:-@handelsen.cn電話:010-64714988-213
    MBS ASK 51.4 2u插入式電流互感器

            主要名稱 電流:100 ... 600 A

  一次電線直徑:最大28 mm

  一次剝皮1:30 x 10 mm

  一次剝皮2:2x 20 x 10mm

  寬度:61 mm

  高度:75.5 mm

  深度:58 mm

  插入式電流互感器,其次級繞組可切換,初級電流范圍為200-100 A至600-300 A,次級電流1或5 A,額定功率2.5至15 VA,精度等級為1。

  可以使用供貨范圍內的安裝腳或標準DIN 35mm導軌的專用夾子來固定變壓器。

  輔助觸點可以用密封蓋固定。

  一般性質

  沒關系 連續熱電流I cth:1.0 x I N

  沒關系 短期熱電流I th:60 x I N,1秒

  過流編號:FS5

  沒關系 動態電流I dynes:2.5 x I th

  最高 工作電壓U m:0.72 kV

  絕緣測試電壓:3 kV,U eff,50 Hz,1分鐘。

  標稱頻率:50赫茲

  絕緣等級:E

  防護等級:IP 20

  工作溫度范圍:-5°C至+ 40°C

  儲存溫度范圍:-25°C至+ 70°C
